ENGINE HONDA OHC 160CC
Product Summary
Honda 160cc premium residential; horizontal shaft engine features overhead cam technology. The GC Series is incredibly quiet and utilizes the world's first internal timing belt. Honda has taken their technology one step further with the development of the GC Series; a line of rugged; powerful and economical overhead cam engines designed specifically for home-use and recreational applications. Common applications: pressure washers; compressors; log splitters and chipper/shredders.
Honda 160cc OHC air-cooled; 4-stroke; horizontal engine
Compact and lightweight design
Compact combustion chamber; overhead cam design and uniblock construction to reduce fuel consumption
Powerful torque across a wide RPM range to help reduce engine speed drop from sudden load increases
Tough resin overhead cam for durability and low noise level
# 60594
Manufacturer's Warranty 24 months consumer / 90 day commercial
Ship Weight 27.0 lbs
Engine Displacement (cc) 160
Start Type Recoil
Application Pressure washer; compressor; log splitter; chipper/shredder
Engine Type GC series OHC premium residential-duty
Net Power Output (HP) 4.6 (3.4 kW) at 3;600 RPM
Net Torque (lbs./ft.) 6.9 (9.4 Nm) at 2;500 RPM
Shaft Output Horizontal
Crankshaft Q-type
Shaft Diameter (in.) 3/4
Shaft Length (in.) 2 7/16
Shaft Keyway (in.) 3/16
Shaft Rotation (From PTO Shaft Side) Counterclockwise
PTO Height (in.) 4 11/64
Bearing Type Standard
Cylinders (qty.) 1
Cylinder Bore Aluminum alloy
Bore x Stroke (in.) 2.5 x 2.0
Compression Ratio 8.5:1
Cooling System Air cooled
Air Cleaner Type Dry (paper) type
Fuel Tank Standard
Fuel Type Gasoline
Fuel Tank Capacity (qt.) 1.9
Fuel Pump Yes
Oil Capacity (qt.) 0.61
Lubrication System Forced splash
Low Oil Alert No
Ignition System Electronic
Governor System Centrifugal mechanical
Carburetor Float
Throttle Control Manual
Max. RPM 3;600
Muffler Included Yes
Bolt Circle (in.) 3 5/8
Mounting Base L x W (in.) 6 3/8 x 2 61/64 to 3 15/32
Dimensions L x W x H (in.) 13 5/16 x 14 1/2 x 13
EPA/CARB Approval (California Air Resource Board) Yes
In stock
Only 2 left
SKU
NTE-60594
TTD3,939.00
Product Summary
Honda 160cc premium residential; horizontal shaft engine features overhead cam technology. The GC Series is incredibly quiet and utilizes the world's first internal timing belt. Honda has taken their technology one step further with the development of the GC Series; a line of rugged; powerful and economical overhead cam engines designed specifically for home-use and recreational applications. Common applications: pressure washers; compressors; log splitters and chipper/shredders.
Honda 160cc OHC air-cooled; 4-stroke; horizontal engine
Compact and lightweight design
Compact combustion chamber; overhead cam design and uniblock construction to reduce fuel consumption
Powerful torque across a wide RPM range to help reduce engine speed drop from sudden load increases
Tough resin overhead cam for durability and low noise level
# 60594
Manufacturer's Warranty 24 months consumer / 90 day commercial
Ship Weight 27.0 lbs
Engine Displacement (cc) 160
Start Type Recoil
Application Pressure washer; compressor; log splitter; chipper/shredder
Engine Type GC series OHC premium residential-duty
Net Power Output (HP) 4.6 (3.4 kW) at 3;600 RPM
Net Torque (lbs./ft.) 6.9 (9.4 Nm) at 2;500 RPM
Shaft Output Horizontal
Crankshaft Q-type
Shaft Diameter (in.) 3/4
Shaft Length (in.) 2 7/16
Shaft Keyway (in.) 3/16
Shaft Rotation (From PTO Shaft Side) Counterclockwise
PTO Height (in.) 4 11/64
Bearing Type Standard
Cylinders (qty.) 1
Cylinder Bore Aluminum alloy
Bore x Stroke (in.) 2.5 x 2.0
Compression Ratio 8.5:1
Cooling System Air cooled
Air Cleaner Type Dry (paper) type
Fuel Tank Standard
Fuel Type Gasoline
Fuel Tank Capacity (qt.) 1.9
Fuel Pump Yes
Oil Capacity (qt.) 0.61
Lubrication System Forced splash
Low Oil Alert No
Ignition System Electronic
Governor System Centrifugal mechanical
Carburetor Float
Throttle Control Manual
Max. RPM 3;600
Muffler Included Yes
Bolt Circle (in.) 3 5/8
Mounting Base L x W (in.) 6 3/8 x 2 61/64 to 3 15/32
Dimensions L x W x H (in.) 13 5/16 x 14 1/2 x 13
EPA/CARB Approval (California Air Resource Board) Yes
| SKU | NTE-60594 |
|---|---|
| Weight | 27.000000 |
| Manufacturer | NORTHERN TOOL |
