TUBE ROUND STL 1.5" A513
PRODUCT FEATURES
All members aluminum alloy 6061-T6
Top and bottom chords are 1-1/2" dia. x 0.125" tubes
Diagnal members are 1/2" solid rods
All end connetion bolts 3/8" - Grade 8
Maximum deflection ? length (inches)/240
UDL = Uniformly Distributed Load
CPL = Center Point Load
All members aluminum alloy 6061-T6
Top and bottom chords are 1-1/2" dia. x 0.125" tubes
Diagnal members are 1/2" solid rods
All end connetion bolts 3/8" - Grade 8
Maximum deflection ? length (inches)/240
UDL = Uniformly Distributed Load
CPL = Center Point Load
Out of stock
SKU
TB-T2112120
TTD3,129.00
INCLUDES
(1) Round Steel Tube
PRODUCT DESCRIPTION
A513 DOM Round Steel Tube, is a welded mechanical round steel tube with the internal weld seam removed creating a smooth internal surface. DOM Round Steel Tube has been drawn over a mandrel to produce a tube having more exact dimensional accuracy and tolerances, and a very smooth inside and outside finish. DOM Round Steel Tube is ideal for more stressful applications requiring higher quality, increased mechanical properties, uniformity, strength, and soundness.
Applications: race car frames, roll cages, motorcycle frames, spindles, rollers, shafts, engine mounts, bushings, cylinders, telescoping, etc.
TECHNICAL SPECIFICATIONS
ASTM A513 Type 5, 1020/1026 mechanical grade
FINISH: Blue / Gray, slightly grainy
CHARACTERISTICS:
Welding = Excellent
Machining / Grinding = Good
Bending / Forming = Fair
Wear Resistance = Fair
Corrosion Resistance = Poor
MECHANICAL PROPERTIES:
Yield Point =70,000 +/- psi
Tensile Strength = 80,000 +/- psi
Elongation = 23% in 2" ; Elasticity = 29 ksi
Brinell Hardness = 80 ; Melting Point = 2600F
Data provided for reference only
AVAILABLE STOCK SIZES:
1ft, 2ft, 4ft, 6ft, 8ft, 10ft, 20ft or Cut to Size
HOW TO MEASURE:
Outside Dimension (A) X Wall Thickness (B)
Item Weight: 1.77lbs/ft
Shipping Weight: 2lbs
(1) Round Steel Tube
PRODUCT DESCRIPTION
A513 DOM Round Steel Tube, is a welded mechanical round steel tube with the internal weld seam removed creating a smooth internal surface. DOM Round Steel Tube has been drawn over a mandrel to produce a tube having more exact dimensional accuracy and tolerances, and a very smooth inside and outside finish. DOM Round Steel Tube is ideal for more stressful applications requiring higher quality, increased mechanical properties, uniformity, strength, and soundness.
Applications: race car frames, roll cages, motorcycle frames, spindles, rollers, shafts, engine mounts, bushings, cylinders, telescoping, etc.
TECHNICAL SPECIFICATIONS
ASTM A513 Type 5, 1020/1026 mechanical grade
FINISH: Blue / Gray, slightly grainy
CHARACTERISTICS:
Welding = Excellent
Machining / Grinding = Good
Bending / Forming = Fair
Wear Resistance = Fair
Corrosion Resistance = Poor
MECHANICAL PROPERTIES:
Yield Point =70,000 +/- psi
Tensile Strength = 80,000 +/- psi
Elongation = 23% in 2" ; Elasticity = 29 ksi
Brinell Hardness = 80 ; Melting Point = 2600F
Data provided for reference only
AVAILABLE STOCK SIZES:
1ft, 2ft, 4ft, 6ft, 8ft, 10ft, 20ft or Cut to Size
HOW TO MEASURE:
Outside Dimension (A) X Wall Thickness (B)
Item Weight: 1.77lbs/ft
Shipping Weight: 2lbs
| SKU | TB-T2112120 |
|---|---|
| Weight | 2.000000 |
| Manufacturer | TRAEGER BROTHERS |
