VBALL 316L 1M NPT 1"
PRODUCT FEATURES
Investment cast components
Reinforced seat
Blow-out proof stem design
Vacuum service to 29 in Hg
150 psig saturated steam
Lead-free - the wetted surfaces of this product shall contain no more than 0.25% lead by weighted average
Cold non-shock body rating
Investment cast components
Reinforced seat
Blow-out proof stem design
Vacuum service to 29 in Hg
150 psig saturated steam
Lead-free - the wetted surfaces of this product shall contain no more than 0.25% lead by weighted average
Cold non-shock body rating
In stock
Only 36 left
SKU
CON-76F10527A
INCLUDES
(1) Apollo™ 76F10527A 76F-100-A 2-Piece Ball Valve, 1 in Nominal, FNPT End Style, Stainless Steel Body, Full Port, MPTFE/RPTFE Softgoods, Domestic
PRODUCT DESCRIPTION
Apollo™, 76F10527A, Ball Valve, 2-Piece, Series: 76F-100-A, 1 in Nominal, FNPT End Style, 1000 psi CWP Pressure, Full Port, Latch-Lock Lever Actuator, 316 Stainless Steel Ball, 3.34 in Inlet to Outlet Length, 2.27 in Top to Inlet Center, Stainless Steel Body, 316 Stainless Steel/RPTFE Trim, MPTFE/RPTFE Softgoods, Domestic
TECHNICAL SPECIFICATIONS
Brand: Apollo™
Item Weight: 1.38 lbs
Nominal Size: 1 in
End Style: FNPT
Pressure Rating: 1000 psi CWP
Body Material: Stainless Steel
Port Type: Full
Softgoods Material: MPTFE/RPTFE
Actuator Type: Latch-Lock Lever
Ball Material: 316 Stainless Steel
Inlet to Outlet Length: 3.34 in
Manufacturer Name: Apollo Conbraco
Series: 76F-100-A
Top to Inlet Center: 2.27 in
Trim Material: 316 Stainless Steel/RPTFE
Type: 2-Piece
Shipping Weight: 2lbs
(1) Apollo™ 76F10527A 76F-100-A 2-Piece Ball Valve, 1 in Nominal, FNPT End Style, Stainless Steel Body, Full Port, MPTFE/RPTFE Softgoods, Domestic
PRODUCT DESCRIPTION
Apollo™, 76F10527A, Ball Valve, 2-Piece, Series: 76F-100-A, 1 in Nominal, FNPT End Style, 1000 psi CWP Pressure, Full Port, Latch-Lock Lever Actuator, 316 Stainless Steel Ball, 3.34 in Inlet to Outlet Length, 2.27 in Top to Inlet Center, Stainless Steel Body, 316 Stainless Steel/RPTFE Trim, MPTFE/RPTFE Softgoods, Domestic
TECHNICAL SPECIFICATIONS
Brand: Apollo™
Item Weight: 1.38 lbs
Nominal Size: 1 in
End Style: FNPT
Pressure Rating: 1000 psi CWP
Body Material: Stainless Steel
Port Type: Full
Softgoods Material: MPTFE/RPTFE
Actuator Type: Latch-Lock Lever
Ball Material: 316 Stainless Steel
Inlet to Outlet Length: 3.34 in
Manufacturer Name: Apollo Conbraco
Series: 76F-100-A
Top to Inlet Center: 2.27 in
Trim Material: 316 Stainless Steel/RPTFE
Type: 2-Piece
Shipping Weight: 2lbs
| SKU | CON-76F10527A |
|---|---|
| Weight | 2.000000 |
| Manufacturer | APOLLO VALVES |
