ROD NI55 ENIFE-CL 1/8"
PRODUCT FEATURES:
Nickel-55 stick electrode for cast iron welding
Designed for repair and joining of cast irons
Suitable for welding cast iron to steel and other alloys
Approx. 55% nickel content reduces cracking and shrinkage stress
Produces ductile, machinable weld deposits
Works in all welding positions
Operates on AC or DC
Ideal for heavy sections and high-phosphorus cast irons
Hermetically sealed packaging maintains electrode quality
In stock
Only 92 left
SKU
OX-5518
TTD229.01
PRODUCT DESCRIPTION:
The Oxford Alloy OX-5518 is a Nickel-55 (ENiFe-CI) stick welding electrode designed for repairing and joining cast iron components. With a balanced nickel-iron composition, it delivers strong, ductile welds with reduced shrinkage stress, minimizing the risk of cracking. This 1/8? electrode is well-suited for heavy castings, machinery repairs, and joining cast iron to steel or other alloys, making it a reliable choice for maintenance and fabrication work.
CHEMICAL COMPOSITION:
Ni: 45.0 - 65.0
C: 2.0 max
Mn: 2.5 max
Fe: Bal
S: 0.03 max
SI: 4.0 max
Cu: 2.5 max
Al: 1.0 max
OET: 1.0 max
MECHANICAL PROPERTIES:
TYPICAL RESULTS - AS WELDED:
Tensile Strength MPa (ksi): 490 (71)
Yield Strength MPs (ksi): 365 (53)
Elongation %: 12
AWS REQUIREMENTS:
Tensile Strength MPa (ksi): 400 - 579 (58 - 84) min
Yield Strength MPs (ksi): 296 - 434 (43 - 63)
Elongation %: 6 - 8
TECHNICAL SPECIFICATIONS:
Brand: Oxford Alloy
Item Model Number: OXF551-8
Product Type: Stick Welding Electrode
AWS Classifications: ENiFe-CI
Diameter: 1/8"
Length: 14"
Material: Nickel Iron Alloy
Welding Process: SMAW
Current Type; AC / DC+
Amperage Range: 85 - 110 A (Flat) / 80 - 90 A (Vertical / Overhead)
Application: Cast Iron Repair & Dissimilar metal welding
Shipping Weight: 10 lbs
| SKU | OX-5518 |
|---|---|
| Weight | 10.000000 |
