GAUGE BRIDGE TYPE WG-8
PRODUCT FEATURES:
Material: High-quality stainless steel
Measurement System: Capable of measuring in both inches and millimeters
Durability: Laser-etched markings ensure clear, wear-resistant readings that will not rub off
Versatility: Measures up to seven different weld criteria
Locking Mechanism: Includes a locking screw to fix measurements in place for easy reading or reference
In stock
Only 6 left
SKU
WP-MG-8
TTD349.00
PRODUCT DESCRIPTION:
This instrument is an all-in-one quality control tool for welders and inspectors. It is typically made from high-strength stainless steel to resist rust and bending in workshop environments. The gauge uses a sliding pointer and a main scale to measure various weld features quickly and accurately in both standard (inches) and metric (millimeters) units. It is used to verify that weldments comply with industry standards on items like boilers, bridges, pressure vessels, and piping.
TECHINCAL SPECIFICATIONS:
Model: MG-8 Bridge Cam Gauge
Material: Stainless Steel
Linear Measurement Range: 0 to 2 inches (0 to 50 mm)
Angle Measurement Range: 0° to 60° (Angle of preparation)
Measures (Specific):
Fillet weld leg length (0 to 25mm / 0 to 1")
Fillet weld throat size (0 to 20mm / 0 to 3/4")
Depth of undercut and pitting (0 to 2mm / 0 to 1/8")
Excess weld metal (capping size)
Outside misalignment (high-low)
Weight: Approximately 0.3 lbs (130g to 150g)
Shipping Weight: 1lb
| SKU | WP-MG-8 |
|---|---|
| Weight | 1.000000 |
